Technical Data

1）Overall size: 2225 x 1070mm
2）Mattress size: 2035 x 1070mm
3）Adjustable height: 380-585mm
4）Angle of back section: 0 – 70°
5）Angle of leg section: 0 – 30°
6）Net Weight: 130KG
7）Box dimension: 1125*190*700mm (Bed end)
1120*235*1100mm (Head frame)
1170*240*1115mm (Foot frame)
8）Loading quantity: 35pcs/20' and 89pcs/40’HQ

Technical Data

1) Overall size: 2235 x 920mm
2) Mattress size: 2020 x 8800mm
3) Adjustable height: 235-585mm
4) Angle of back section: 0 – 70°
5) Angle of leg section: 0 – 30°
6) Net Weight: 95KG
7) Box dimension: 1120*205*950mm (Head assembly)
1205*260*950mm (Foot assembly)
8) Loading quantity: 50pcs/20' and 128pcs/40'HQ

Technical Data

1) Overall size: 2235 x 920mm
2) Mattress size: 2020 x 880mm
3) Adjustable height: 385-585mm
4) Angle of back section: 0 – 70°
5) Angle of leg section: 0 – 40°
6) Net Weight: 95KG
7) Box dimension: 1120*205*950mm (Head assembly),
1205*260*950mm (Foot assembly)
8) Loading quantity: 50pcs/20'and 128pcs/40'HQ

Technical Data

1) Overall size: 2235 x 920mm
2) Mattress size: 2020 x 880mm
3) Adjustable height: 380-585mm
4) Angle of back section: 0 – 70°
5) Angle of leg section: 0 – 40°
6) Net Weight: 75.6KG
7) Box dimension: 960*205*695mm (bed end)
950*260*1160mm ( bed platform)
8) Loading quantity: 55pcs/20’’and 155pcs/40’HQ

Technical Data


1) Overall size: 2250 x 920mm
2) Mattress size: 1990 x 880mm
3) Adjustable height: 110-710mm
4) Angle of back section: 0 – 70°
5) Angle of leg section: 0 – 35°
6) Angle of tilting: ±15°
7) Net Weight: 96KG
8) Box dimension: 2330*960*270mm ( 1 bed with 1 pallet)
9) Loading quantity: 96pcs/40’HQ

Technical Data

1) Overall size: 2160 – 2385mm(extended) x 865mm
2) Mattress size: 1930 x 810mm
3) Adjustable height: 265-650mm
4) Angle of back section: 0 – 80°
5) Angle of leg section: 0 – 30°
6) Net Weight: 95KG
7) Box dimension: 2150*910*315mm ( 3 or 4 beds with 1 steel pallet)
8) Loading quantity: 81pcs/40'HQ

Features

1) Made of steel frame with coating surface
2) Back and Knee control by motor, Hi/Lo control by hand crank
3) The plastic grain panels are break and scratch resistant
4) Channel frame construction provides superior strength and reduced weight.
5) Zinc-coated spring deck
6) Unique motor is completely self-contained to reduce weight and noise
7) The motor assembly can be install

Technical Data

1) Overall size: 2055 x 990mm
2) Mattress size: 1850 x880mm
3) Adjustable height: 280-710mm
4) Angle of back section: 0 – 60°
5) Angle of leg section: 0 – 30°
6) Net Weight: 98KG
7) Box dimension: 2130 x 950 x 320mm
8) Loading quantity: 84pcs/40'

Technical Data

1) Overall size: 2170 x 1030mm
2) Mattress size: 1960 x900mm
3) Adjustable height: 450-800mm
4) Angle of back section: 0 – 70°
5) Angle of leg section: 0 – 35°
6) Angle of tilting: ±10°
